| Quotation for pipeline water dispenser | |||
| Model | YLRT-N3-UF(with 4 stage filters) | ||
| Product Feature | Available with hot&cold water, floor standing water dispenser, with 4 stage filters inside including UF membrane, water pipe connection:food grade silicon gel tubes | ||
| Power Supply | AC 220~ 240V 50-60Hz | ||
| Power Consumption | Hot | 500W | |
| Cold | 90W | ||
| Hot | Heater type | Inner heater | |
| Tank material | SS 304 | ||
| Temp range | 85-95℃ | ||
| Temp control | Bimetal thermostat | ||
| Volume of tank | 1.0L | ||
| Cold | Cooling system | Compressor cooling | |
| Tank type | SS 304 | ||
| Refrigerant | R134a | ||
| Temp range | 6-10℃ | ||
| Volume of tank | 3.2L | ||
| UF system | stage 1: PPF | Remove the suspended solids, particle, rust and other impurities. | |
| stage 2: CTO | Deeply adsorb odor, color, residual chlorine, halogenated substances and harmful material | ||
| stage 3: UF/RO | Remove the bacteria, heavy metals, salt, bad mineral substance, other dissolved matter and chemical drug | ||
| stage 4: T33 | Adsorb bad smell and make water taste good | ||
| Colors available | white&black | ||
| N.W | 14kg | ||
| G.W | 14.8kg | ||
| Product size | 32x34x50cm | ||
| Box size | 325*525*525mm | ||
| Loading qty | 20ft/40HQ | 308pcs/770pcs | |
